Línea de llenado de bebidas carbonatadas

We supply complete solution for the Carbonated beveragefilling plant including Water treatment system/Carbonated beverage mixing system/Washingfiling capping machine/Code sprayer/Pasteurizer tunnel /Automatic labelingmachine/Automatic packing machine/Automatic Palletizer system.

Technical parameter:carbonated beverage filling machine
Model	DCGF8-8-3	DCGF16-12-6	DCGF18-18-6	DCGF24-24-8	DCGF32-32-10	DCGF40-40- 12
Capacity(for 500ml)	1000BPH	2000BPH	3000BPH	5000BPH	6000BPH	10000BPH
Suitable bottle shapes	PET circular or square
Bottle diameter(mm)	Dia50-Dia115mm
Bottle height (mm)	160-320mm
Compressor air	0.3-0.7Mpa
Washing meidium	Aseptic water
Rinsing pressure	>0.06Mpa <0.2Mpa
Application	Carbonated drink filling machine
Total power(KW)	3kw	4.4kw	5.2kw	6.2kw	7.5kw	8.2kw
Overalldimensions	2*1.6m	2.6*1.8m	3*1.8m	3.5*2m	3.8*2.2m	4.5*2.4m
Height	2.3m	2.3m	2.5m	2.5m	2.5m	2.6m
Weight(kg)	1500kg	2000kg	2500kg	3000kg	3500kg	4500kg
